Generic Name: 乙烯四氟乙烯共聚物 (ETFE) - 提供方: The Chemours Company
Tefzel ? ETFE HT-2183 is a premium fluoroplastic resin available in translucent, 2.5-mm (0.1-in) pellets. Compared with other grades of Tefzel ? , its most unique features are a greatly enhanced flex life and resistance to environmental stress.
Tefzel ? HT-2183 and the other Tefzel ? fluoropolymers are melt processible, modified copolymers of ethylene and tetrafluoroethylene. They are high-performance resins that can be processed at relatively high rates compared with other fluorocarbon resins. They are mechanically tough and offer an excellent balance of properties.
Tefzel ? HT-2183 is preferred for applications where other thermoplastics are lacking in mechanical toughness; broad thermal capability; ability to meet unusual thermal, mechanical, and chemical environmental extremes; or limited by fabricating problems. Examples are components and linings for the chemical industry and molded parts with metal inserts or thick sections for use at high temperatures.
Properly processed products made from neat Tefzel ? HT-2183 are inert to most solvents and chemicals, hydrolytically stable, and weather-resistant. The recommended upper service temperature is 155°C (311°F); useful properties are retained at cryogenic ranges. The level and stability of dielectric properties are excellent and the flame rating is V-0 by the UL94 method. They are resistant to environmental stress cracking and have outstanding impact strength, cutthrough, and abrasion resistance. Statements, or data, regarding behavior in a flame situation are not intended to reflect hazards presented by this or any other material when under actual fire conditions.
Typical End Products
Tefzel ? HT-2183 is ideal for many end products, including chemical service items, such as lined valves and fittings, pump housings and impellers, column packings, and other abrasion-resistant linings; high-temperature electrical components and insulation; fasteners, corrugated tubing, and duct work; and film.
與典型值比較 - Upgrade to compare! 與黃卡比較
單位: SI
總覽
材料狀態
已商用：當前有效
資料 1Technical Datasheet (English)
UL 黃卡 2E5468
搜索 UL 黃卡The Chemours Company
Tefzel?
供貨地區北美洲
拉丁美洲
歐洲
亞太地區
特性Excellent Weather Resistance
高 ESCR（抗應力開裂）
高抗撞擊性
共聚物
抗溶劑性
良好的電氣性能
耐化學品性能，良好
耐磨損性，良好
韌性良好
水解穩定
用途薄膜
泵件
襯里
電氣/電子應用領域
電子絕緣
閥門/閥門部件
管件
緊固件
內襯，耐磨
配件
外觀半透明
形式粒子
加工方法吹塑成型
擠出
樹脂傳遞成型
壓縮模塑
注射成型
物理性能額定值
單位制
測試方法
密度 / 比重1.70
g/cm3
ASTM D792表觀密度1.30
g/cm3
內部方法熔流率（熔體流動速率） (297°C/5.0 kg)6.0
g/10 min
ASTM D3159吸水率 (24 hr)7.0E-3
%
ASTM D570機械性能額定值
單位制
測試方法
抗張強度 (23°C)41.4
MPa
ASTM D638伸長率 (斷裂, 23°C)300
%
ASTM D638彎曲模量 (23°C)1000
MPa
ASTM D790沖擊性能額定值
單位制
測試方法
懸壁梁缺口沖擊強度 (23°C)無斷裂
額定值
單位制
測試方法
肖氏硬度 (邵氏 D)67
額定值
單位制
測試方法
熔融溫度255 到 280
°C
ASTM D3418線形熱膨脹系數 - 流動 (0 到 100°C)1.3E-4
cm/cm/°C
ASTM D696最高使用溫度155
°C
UL 746電氣性能額定值
單位制
測試方法
體積電阻率1.0E+17
ohms·cm
ASTM D257介電強度 (0.250 mm)70
kV/mm
ASTM D149介電常數 (23°C, 1 MHz)2.50 到 2.60
7.2E-3
額定值
單位制
測試方法
UL 阻燃等級V-0
30 到 32
%
ASTM D2863
