| 品牌： | 美國科慕/杜邦 |
| 包裝： | 25KG/包 |
| 產地： | 美國科慕/杜邦 |
| 單價： | 260.00元/千克 |
| 發貨期限： | 自買家付款之日起 天內發貨 |
| 所在地： | 直轄市 天津 |
| 有效期至： | 長期有效 |
| 發布時間： | 2023-11-23 23:28 |
| 最后更新： | 2023-11-23 23:28 |
| 瀏覽次數： | 215 |
| 采購咨詢： |
請賣家聯系我
|
Generic Name: 乙烯四氟乙烯共聚物 (ETFE) - 提供方: The Chemours Company
Tefzel? ETFE HT-2185 is a special purpose fluoroplastic resin available in translucent, 2.5-mm (0.1-in) pellets. Compared with other grades of Tefzel?, it has a higher flow rate.
Tefzel? HT-2185 and the other Tefzel? fluoropolymers are melt processible, modified copolymers of ethylene and tetrafluoroethylene. They are high-performance resins that can be processed at relatively high rates compared with fluorocarbon resins. They are mechanically tough and offer an excellent balance of properties.
The relatively high flow rate of Tefzel? HT-2185 makes it uniquely suitable for high-speed processing, especially for extruded coatings and injection molding of slender, thin-walled, or intricate shapes. Molded or extruded products made from Tefzel? HT-2185 are preferred for uses that do not involve significant flexural or tensile stress at elevated temperatures. Higher viscosity products such as Tefzel? HT-2181 and Tefzel? HT-2183 are preferred for these applications.
Properly processed products made from neat Tefzel? HT-2185 are inert to most solvents and chemicals, hydrolytically stable, and weather-resistant. The recommended upper service temperature is 150°C (302°F); useful properties are retained at cryogenic ranges. The level and stability of dielectric properties are excellent, and the flame rating is V-0 by the UL94 method. Mechanical properties include outstanding impact strength, cut-through, and abrasion resistance.
Statements, or data, regarding behavior in a flame situation are not intended to reflect hazards presented by this or any other material when under actual fire conditions.
Typical End Products
Tefzel ? HT-2185 is ideal for many end products, including electrical components, such as sleeving, coil forms, sockets, connectors, and switches; lab ware, such as tubing, valves, containers, and fasteners; battery or instrument components that require chemical inertness; and mechanical parts.
與典型值比較 - Upgrade to compare! 與黃卡比較
單位: SI
總覽
材料狀態
已商用：當前有效
資料 1Technical Datasheet (English)
UL 黃卡 2E5468
搜索 UL 黃卡The Chemours Company
Tefzel?
供貨地區北美洲
拉丁美洲
歐洲
亞太地區
特性Excellent Weather Resistance
高抗撞擊性
共聚物
抗溶劑性
良好的電氣性能
流動性高
耐化學品性能，良好
耐磨損性，良好
韌性良好
水解穩定
用途薄壁部件
電氣/電子應用領域
閥門/閥門部件
管件
緊固件
開關
連接器
容器
實驗室器具
外觀半透明
形式粒子
加工方法吹塑成型
擠出
擠出涂層
樹脂傳遞成型
壓縮模塑
注射成型
物理性能額定值
單位制
測試方法
密度 / 比重1.70
g/cm3
ASTM D792表觀密度1.30
g/cm3
內部方法熔流率（熔體流動速率） (297°C/5.0 kg)11
g/10 min
ASTM D3159吸水率 (24 hr)7.0E-3
%
ASTM D570機械性能額定值
單位制
測試方法
抗張強度 (23°C)41.4
MPa
ASTM D638伸長率 (斷裂, 23°C)300
%
ASTM D638彎曲模量 (23°C)1000
MPa
ASTM D790壓縮強度37.9
MPa
ASTM D695沖擊性能額定值
單位制
測試方法
懸壁梁缺口沖擊強度 (23°C)無斷裂
額定值
單位制
測試方法
熔融溫度255 到 280
°C
ASTM D3418線形熱膨脹系數 - 流動 (0 到 100°C)1.3E-4
cm/cm/°C
ASTM D696最高使用溫度155
°C
UL 746電氣性能額定值
單位制
測試方法
體積電阻率1.0E+17
ohms·cm
ASTM D257介電強度 (0.250 mm)70
kV/mm
ASTM D149介電常數 (23°C, 1 MHz)2.50 到 2.60
5.4E-3
額定值
單位制
測試方法
UL 阻燃等級V-0
30 到 32
%
ASTM D2863
