Tefzel? 750 Gas Igniter ETFE美國杜邦210耐腐蝕 減磨耐磨 電纜絕緣層 防腐設備

Generic Name: 乙烯四氟乙烯共聚物 (ETFE) - 提供方: The Chemours Company

DuPont? Tefzel ? fluoropolymer resins offer mechanical strength and toughness along with resistance to heat and chemicals. In addition, they provide easy processing, high specific dielectric strength, and a low coefficient of friction. For these reasons, Tefzel ? resins are widely used to make compact wire and cable constructions that provide long, reliable service in demanding environments.

Tefzel ? 750 retains the traditional characteristics of Tefzel ? resins while providing some new property advantages, including increased flexibility and improved retention of properties after aging at elevated temperatures, higher limiting oxygen index, and long-term service life at higher temperatures than other Tefzel ? resins.

Underwriters Laboratories, Inc. (UL) has rated wire insulated with Tefzel ? 750 (10 mil for 600V, 6 mil for 300V) for service in appliances at a maximum continuous operating temperature of 200°C (392°F). This rating was determined under the guidelines of UL Subject 758 for appliance wiring material. Upper service temperatures for other applications should be determined under the guidelines for those applications. Temperature ratings may not be the same as the rating for appliance wire because the test procedures are different.

Typical End Products
Tefzel ? ETFE 750 fluoroplastic resin can be used for wire service at up to 200 °C (392 °F).Tefzel ? ETFE 750 can also be used as insulation for applications where customers need the basic benefits of Tefzel ? together with increased flexibility and improved retention of properties after aging at elevated
temperatures. Flexibility is desirable for ease of handling during maintenance and repair procedures.

 與典型值比較 - Upgrade to compare!  與黃卡比較

單位: SI

總覽
材料狀態

已商用：當前有效

資料 1

Technical Datasheet (English)

UL 黃卡 2

E

搜索 UL 黃卡

The Chemours Company

Tefzel?

供貨地區

北美洲

拉丁美洲

歐洲

亞太地區

特性

低摩擦系數

共聚物

良好的加工性能

良好的柔韌性

耐化學品性能，良好

耐熱性，高

韌性良好

用途

電線電纜應用

電子絕緣

形式

粒子

加工方法

擠出

物理性能

額定值

單位制

測試方法

密度 / 比重

1.75 到 1.79

g/cm3

ASTM D792熔流率（熔體流動速率） (297°C/5.0 kg)

7.0

g/10 min

ASTM D3159機械性能

額定值

單位制

測試方法

抗張強度

ASTM D170823°C

37.9

MPa

140°C

11.4

MPa

160°C

8.62

MPa

180°C

6.21

MPa

200°C

3.45

MPa

伸長率

ASTM D1708斷裂, 23°C

300

%

斷裂, 140°C

600

%

斷裂, 160°C

650

%

斷裂, 180°C

600

%

斷裂, 200°C

600

%

彎曲模量

645

MPa

ASTM D790熱性能

額定值

單位制

測試方法

熔融溫度

219 到 254

°C

ASTM D3159可燃性

額定值

單位制

測試方法

極限氧指數

34

%

ASTM D2863補充信息

額定值

單位制

測試方法

MIT Flexural Life

120000

擠出

額定值

單位制

料筒1區溫度

288

°C

料筒2區溫度

316

°C

料筒3區溫度

321

°C

接頭溫度

321

°C

熔體溫度

332 到 335

°C

口模溫度

332

°C
